C ONNECT THE S YSTEM
2-7
Installing a Splitterless Connection
If you are using a splitterless (G.lite) connection, then your service
provider will attach the outside ADSL line directly to your phone system.
Use a straight through CAT-5 Ethernet cable (RJ-45) to connect the
Barricade to the cable/DSL modem. You will have to add low-pass filters
to your phones as shown below:
Figure 2-4. Installing without a Splitter
Plain Old
Telephone
System (POTS)
Filter
or
Ethernet
hub or switch
Voice
& Data
Voice
& Data
Data
Voice
Residential
Connection
Point [Network
Interface
Device (NID)]
Barricade
Modem
