-16-
No.DOC1048575-1
4.1.3. Pressure value (same mapping in each CH)
Table 4-4. Pressure value (Pressure range: -100...100 kPa)
Type
Size
Offset
Name
Data
Pressure value [kPa]
INT
2.0
0.0
Pressure value CHx
0
0.0
1
0.1
...
...
999
99.9
1000
100.0 or more
-
Indefinite
-1000
-100.0 or less
-999
-99.9
...
...
-2
-0.2
-1
-0.1
Table 4-5. Pressure value (Pressure range: -100...200 kPa)
Type
Size
Offset
Name
Data
Pressure value [kPa]
INT
2.0
0.0
Pressure value CHx
0
0.0
1
0.1
...
...
1999
199.9
2000
200.0 or more
-
Indefinite
-1000
-100.0 or less
-999
-99.9
...
...
-2
-0.2
-1
-0.1
NOTE
 For the pressure range setting, refer to Section 5.1.10.
 If a pressure sensor failure/disconnection occurs, if the pressure sensor use setting
(Section 5.1.7) is Unused, or if a pressure sensor short circuit occurs, the data is set to 0.
