4. Process data
Table 4-1. Overview of process data
Input/Output
Index
Name
Size
Description
Input
0x1A00
Vacuum confirmation
1.0
or 2.0
Refer to Section 4.1.1 or Section 4.1.2.
In the 3.2 vacuum manifold stations setting,
Size is 1.0 for 4 or 8 stations and 2.0 for 12 or
16 stations.
0x1A01
Release confirmation
1.0
or 2.0
0x1A10
Pressure value CH0
2.0
Refer to Section 4.1.3.
The number of CHs displayed depends on the
3.2 vacuum manifold stations setting.
0x1A11
Pressure value CH1
2.0
0x1A12
Pressure value CH2
2.0
0x1A13
Pressure value CH3
2.0
0x1A14
Pressure value CH4
2.0
0x1A15
Pressure value CH5
2.0
0x1A16
Pressure value CH6
2.0
0x1A17
Pressure value CH7
2.0
0x1A18
Pressure value CH8
2.0
0x1A19
Pressure value CH9
2.0
0x1A1A
Pressure value CH10
2.0
0x1A1B
Pressure value CH11
2.0
0x1A1C
Pressure value CH12
2.0
0x1A1D
Pressure value CH13
2.0
0x1A1E
Pressure value CH14
2.0
0x1A1F
Pressure value CH15
2.0
0x1A20
Channel status CH0
2.0
Refer to Section 4.1.4.
The number of CHs displayed depends on the
3.2 vacuum manifold stations setting.
0x1A21
Channel status CH1
2.0
0x1A22
Channel status CH2
2.0
0x1A23
Channel status CH3
2.0
0x1A24
Channel status CH4
2.0
0x1A25
Channel status CH5
2.0
0x1A26
Channel status CH6
2.0
0x1A27
Channel status CH7
2.0
0x1A28
Channel status CH8
2.0
0x1A29
Channel status CH9
2.0
0x1A2A
Channel status CH10
2.0
0x1A2B
Channel status CH11
2.0
0x1A2C
Channel status CH12
2.0
0x1A2D
Channel status CH13
2.0
0x1A2E
Channel status CH14
2.0
0x1A2F
Channel status CH15
2.0
0x1A30
Unit status
2.0
Refer to Section 4.1.5.
Output
0x1600
Vacuum instruction
1.0
or 2.0
Refer to Section 4.2.1 or Section 4.2.2.
In the 3.2 vacuum manifold stations setting,
Size is 1.0 for 4 or 8 stations and 2.0 for 12 or
16 stations.
0x1601
Release instruction
1.0
or 2.0
