SMC Networks EtherCAT EX260-VEC1 - Input Process Data

-15-
No.DOC1048575-1
4.1. Input process data
4.1.1. Vacuum status
Table 4-2. Vacuum status
Type
Size
Offset
Name
Description
BIT
0.1
0.0
Vacuum confirmation CH0
0: No vacuum adsorption
1: During vacuum adsorption
The vacuum status thresholds and hysteresis are
set in Sections 5.1.1 and Section 5.1.2.
Valid values are up to CH3 for the vacuum manifold
4-stations setting, up to CH7 for the 8-stations
setting and up to CH11 for the 12-stations setting.
BIT
0.1
0.1
Vacuum confirmation CH1
BIT
0.1
0.2
Vacuum confirmation CH2
BIT
0.1
0.3
Vacuum confirmation CH3
BIT
0.1
0.4
Vacuum confirmation CH4
BIT
0.1
0.5
Vacuum confirmation CH5
BIT
0.1
0.6
Vacuum confirmation CH6
BIT
0.1
0.7
Vacuum confirmation CH7
BIT
0.1
1.0
Vacuum confirmation CH8
BIT
0.1
1.1
Vacuum confirmation CH9
BIT
0.1
1.2
Vacuum confirmation CH10
BIT
0.1
1.3
Vacuum confirmation CH11
BIT
0.1
1.4
Vacuum confirmation CH12
BIT
0.1
1.5
Vacuum confirmation CH13
BIT
0.1
1.6
Vacuum confirmation CH14
BIT
0.1
1.7
Vacuum confirmation CH15
4.1.2. Release status
Table 4-3. Release status
Type
Size
Offset
Name
Description
BIT
0.1
0.0
Release confirmation CH0
0: No vacuum release
1: During vacuum release
The release status thresholds and hysteresis are
set in Sections 5.1.5 and Section 5.1.6.
Valid values are up to CH3 for the vacuum manifold
4-stations setting, up to CH7 for the 8-stations
setting and up to CH11 for the 12-stations setting.
BIT
0.1
0.1
Release confirmation CH1
BIT
0.1
0.2
Release confirmation CH2
BIT
0.1
0.3
Release confirmation CH3
BIT
0.1
0.4
Release confirmation CH4
BIT
0.1
0.5
Release confirmation CH5
BIT
0.1
0.6
Release confirmation CH6
BIT
0.1
0.7
Release confirmation CH7
BIT
0.1
1.0
Release confirmation CH8
BIT
0.1
1.1
Release confirmation CH9
BIT
0.1
1.2
Release confirmation CH10
BIT
0.1
1.3
Release confirmation CH11
BIT
0.1
1.4
Release confirmation CH12
BIT
0.1
1.5
Release confirmation CH13
BIT
0.1
1.6
Release confirmation CH14
BIT
0.1
1.7
Release confirmation CH15
