8. Specification
8.1. Specifications
Table 8-1. Specifications
Item
Specification
General
Protection class
IP67 (when connected with the vacuum manifold, it is IP65)
Standards
CE/UKCA Marking
Dimensions (W x L x H)
25.5 x 98.7 x 76.5
Housing material
PBT
Weight
150 g
Maximum number of ejectors
16
Maximum number of sensors
16
Withstand voltage
500 VAC 1 min. (between FE and all accessible terminal)
Insulation resistance
10 M ohm or more (500 VDC between FE and all accessible terminal)
Operating temperature range
0 °C...50 °C
Storage temperature range
-20 °C...60 °C
Operating humidity range
35 %...85 %RH (non-condensing)
Electrical
For logic/input
Operating voltage
24 VDC +10%/-10%
Current consumption
100 mA or less (at 24 VDC)
Under-voltage detection
approx. 18 VDC
For output
Operating voltage
24 VDC +10%/-5%
Protection against polarity reversal
Yes (PWR and PWR(V))
Loop through current between power
connectors
4 A
Galvanic isolation
Yes (between PWR and PWR(V))
Fieldbus
Bus protocol
EtherCAT
®
Version
Conformance Test Record V2.3.0
Communication speed
100 Mbps
FoE
Supported
CoE
Supported for parameter setting and diagnostics etc.
Configuration file
XML file
Vendor ID
0x00000114
Product Code
0x0100004F
