4.2. Output process data
4.2.1. Vacuum instruction
Table 4-8. Vacuum instruction
Type
Size
Offset
Name
Description
BIT
0.1
0.0
Vacuum instruction CH0
Supply valve type: N.O.
0: Vacuum instruction ON
1: Vacuum instruction OFF
Supply valve type: N.C.
0: Vacuum instruction OFF
1: Vacuum instruction ON
For supply valve type setting, refer to Section 5.1.8.
Valid values are up to CH3 for the vacuum manifold
4-stations setting, up to CH7 for the 8-stations
setting and up to CH11 for the 12-stations setting.
BIT
0.1
0.1
Vacuum instruction CH1
BIT
0.1
0.2
Vacuum instruction CH2
BIT
0.1
0.3
Vacuum instruction CH3
BIT
0.1
0.4
Vacuum instruction CH4
BIT
0.1
0.5
Vacuum instruction CH5
BIT
0.1
0.6
Vacuum instruction CH6
BIT
0.1
0.7
Vacuum instruction CH7
BIT
0.1
1.0
Vacuum instruction CH8
BIT
0.1
1.1
Vacuum instruction CH9
BIT
0.1
1.2
Vacuum instruction CH10
BIT
0.1
1.3
Vacuum instruction CH11
BIT
0.1
1.4
Vacuum instruction CH12
BIT
0.1
1.5
Vacuum instruction CH13
BIT
0.1
1.6
Vacuum instruction CH14
BIT
0.1
1.7
Vacuum instruction CH15
4.2.2. Release instruction
Table 4-9. Release instruction
Type
Size
Offset
Name
Description
BIT
0.1
0.0
Release instruction CH0
0: Release instruction OFF
1: Release instruction ON
Valid values are up to CH3 for the vacuum manifold
4-stations setting, up to CH7 for the 8-stations
setting and up to CH11 for the 12-stations setting.
BIT
0.1
0.1
Release instruction CH1
BIT
0.1
0.2
Release instruction CH2
BIT
0.1
0.3
Release instruction CH3
BIT
0.1
0.4
Release instruction CH4
BIT
0.1
0.5
Release instruction CH5
BIT
0.1
0.6
Release instruction CH6
BIT
0.1
0.7
Release instruction CH7
BIT
0.1
1.0
Release instruction CH8
BIT
0.1
1.1
Release instruction CH9
BIT
0.1
1.2
Release instruction CH10
BIT
0.1
1.3
Release instruction CH11
BIT
0.1
1.4
Release instruction CH12
BIT
0.1
1.5
Release instruction CH13
BIT
0.1
1.6
Release instruction CH14
BIT
0.1
1.7
Release instruction CH15
NOTE
 "0" indicates that the supply or release valve is energization OFF and "1" indicates that the supply or
release valve is energization ON.
 If vacuum instruction and release instruction are turned ON simultaneously on one CH, the vacuum
instruction has priority and only the supply valve is opened.
