FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 34 -
TECHNICAL DATA:
Dimensions:
Table of slotted aluminium , 450 x 582 mm. Height 900 mm.
Air treatment unit:
Filter to 5 µm, pressure regulator and pressure gauge.
Control panel:
Start, stop, reset pushbuttons. Emergency stop button, main switch on/off,
mode selector (auto-man) and error pilot indicator.
Composition of module manipulators:
Height measuring manipulator
Actuators:
- Centering device: Compact single-acting cylinder Ø12, Stroke: 5mm
(CQ2B12-5S). Controlled by 3/2 way monostable solenoid valve.
- Vertical axis: Rodless cylinder Ø16, Stroke: 250mm (MY1M16G-250), with
flow regulators and initial-end position detectors. Controlled by 5/2 way bistable
solenoid valve.
- Incorrect bearing rejection: Double-acting cylinder Ø10, Stroke: 40mm
(CD85N10-40-B), with flow regulators. Controlled by 5/2 way monostable
solenoid valve.
Sensors:
- Reed type magnetic detectors (D-A93L).
- Linear potentiometer GEFRAN (PY-2-F-025-S02M).
Bearing insertion manipulator
Actuators:
- Compact double-acting cylinder with guide Ø16, Stroke: 30mm (MGPM16-30),
with flow regulators and initial-end position detectors. Controlled by 5/2 way
monostable solenoid valves.
