FLEXIBLE ASSEMBLY SYSTEM FAS200
User Manual for FAS200 - 55 -
Sensors:
- Reed type magnetic detectors (D-Z73L).
- Vacuum switch PNP output (PS-1100-R06L).
Electrical control panel:
- Mounted on perforated mesh
- Accessible terminal plate with supply connections and coded I/Os.
- I/O station: 18 inputs, 11 outputs.
- Supply module: 24V/60W
- PLC control:
• CPU with digital inputs/outputs.
• Communication module for PLC network connection.
