4 How to use
-79-
No.PS※※-OMW0009-A
■[F98] Output check
Correct operation of the switch output can be confirmed.
The output can be turned ON/OFF manually.
<Operation>
Press the UP or DOWN button in function selection mode to display [F98].
Press the SET button. Move on to output check.
Output check
Press the UP or DOWN button to select output check.
Press the SET button to set.
OUT1 output check
Press the UP or DOWN button to select OUT1 output
check.
: When used with IO-Link communication, the operation indicator
light and displayed colour (when OUT1 is interlocked) will change.
Press the SET button to set.
[n] (Normal output) is
selected
Press the SET button
to set.
Return to function
selection mode.
[F] (Forced output) is selected
Press the SET button to set.
