2 About this product
-15-
No.PS※※-OMW0009-A
Specification
■Specifications (ISA3)
Model
ISA3-F
ISA3-G
ISA3-H
Applicable fluid
Dry air (Filtered through a 5 μm filter)
OUT1
4
OUT2
5
Rated distance range
0.01 to 0.03 mm
0.02 to 0.15 mm
0.05 to 0.30 mm
Displayable/settable range
(Distance reference)
1
0 to 60
2
10 to 300
2
30 to 500
2
Min. display unit
(Distance reference)
1
1
Rated pressure range
100.0 to 200.0 kPa
Displayable range
(Pressure value)
3
-20.0 to 220.0 kPa
Repeatability
0.005 mm or less
0.010 mm or less
0.020 mm or less
Temperature characteristics
(Reference: 25
o
C)
0.010 mm or less
0.015 mm or less
0.030 mm or less
Hysteresis
0 to variable
(Default: 3)
0 to variable (Default: 20)
OUT2
6
Rated pressure range
0.0 to 200.0 kPa
Setting pressure range
-20.0 to 220.0 kPa
Min. display/setting unit
0.1 kPa
Repeatability
±0.5%F.S.±1 digit
Temperature characteristics
(Reference: 25
o
C)
±2%F.S.
Hysteresis
Hysteresis mode
Variable from 0
7
Window comparator mode
Withstand pressure
600 kPa
Detection nozzle
1.5
8
Current flow
5 L/min
12 L/min
22 L/min
Electric spec.
Power supply
voltage
Used as switch output
device
24 VDC±10% with 10% voltage ripple or less
Used as IO-Link device
18 to 30 VDC, including ripple (p-p) 10%
Current consumption
25 mA or less
Protection
Polarity protection
Switch output
Select from NPN or PNP open collector output
Max. load current
10 mA
Max. applied voltage
30.0 V
Residual voltage
1 V or less (at 10 mA)
Short circuit protection
Provided
Display
2-screen (3-screen display available: sub display, 4 digits x 2)
Main display: 4 digits, 7-segments 2-colour (Orange/Green)
Sub display: 9 digits (Upper 9 digits, 4 digits, 3 digits 11-segments,
7-segments for other)
