2 About this product
-16-
No.PS※※-OMW0009-A
Model
ISA3-F
ISA3-G
ISA3-H
Environment
Enclosure
IP67 equivalent
9
Operating temp. range
Operation: 0 to 50
o
C, Stored: -20 to 70
o
C (No condensation or freezing)
Operating humidity range
Operation/Stored: 35 to 85%RH (No condensation)
Withstand voltage
1000 VAC or more (in 50/60 Hz) for 1 minute between terminals and housing
Insulation resistance
2 MΩ or more at 500 VDC, between terminals and housing
Piping spec.
Piping
option
C
Supply port
Rc1/8
Detection port
4 One-touch fitting
6 One-touch fitting
Piping
option
F
Supply port
G1/8 (ISO1179-1)
Detection port
G1/8 (ISO1179-1)
Cable
Lead wire with connector
M12 lead wire with 4 pin connector, 4 cores 4 5 m
Centralized lead wire
M12 lead wire with 4 pin connector part, 4 cores, 4, Insulator O.D.: 1.14 mm
Centralized lead wire part, 2 to 3 stations: 8 cores, 6, 5 m
4 to 6 stations: 14 cores, 6, 5 m
Conductor O.D.: 0.50 mm, Insulator O.D.: 1.00 mm (2 to 6 stations common)
Weight
113 g (Cable not included, One-touch fitting)
Standard
CE marked (EMC directive/RoHS directive)
Communication spec.
(During IO
-Link mode)
IO-Link type
Device
IO-Link version
V1.1
Communication speed
COM2 (38.4 kbps)
Configuration file
IODD file
10
Min. cycle time
4.2 ms
Process data length
Input Data: 8 byte, Output Data: 0 byte
On request data
communication
Available
Data storage function
Available
Event function
Available
Vendor ID
131 (0x0083)
Device ID
ISA3-FL-341 (0x0155)
ISA3-GL-342 (0x0156)
ISA3-HL-343 (0x0157)
1: Refer to the relationship between the display value and distance on page 20 for details.
2: For ISA3-F type, the range is up to 57, with a hysteresis of 3.
For ISA3-G type, the range is up to 280, with a hysteresis of 20.
For ISA3-H type, the range is up to 480, with a hysteresis of 20.
3: The pressure value will be indicated on the sub display.
4: When used as a switch output device in SIO mode.
5: When OUT2 is set to distance detection.
6: When OUT2 is set to pressure detection.
7: If the pressure fluctuates around the set value, the hysteresis must be set to a value more than the amount of fluctuation, otherwise
chattering will occur.
8: See the figure on page 29 for details of the detection nozzle.
9: Applies only to the digital gap checker body excluding the control unit.
10: The configuration file can be downloaded from the SMC website, http://www.smcworld.com
11: Any products with tiny scratches, smears, or display colour variation or brightness which does not affect the performance are verified
as conformant products.
