○Diagnostic information
This product can detect the device error by diagnostic bit in the process data.
Item
Content
Pressure diagnostics
When the pressure gauge measurement value (SUP side or OUT side) is below the
lower display limit (-20 kPa), the diagnostic bit will be "1: ON".
Error diagnostics
Diagnostic bit will be "1: ON" when either of the following errors is generated.
•Internal product malfunction
•OUT2 over current
•Internal product abnormal temperature
○Relationship between the process data and display value
Content
Unit
Rated pressure range
Display/settable range
SUP port pressure value/
OUT port pressure value
kPa
0.0 to 200.0
-20.0 to 220.0
bar
0.000 to 2.000
-0.200 to 2.200
psi
0.00 to 29.00
-2.90 to 31.9
Process data
0 to 2000
-200 to 2200
Content
Type
Item
Display/settable range
Display
value
(clearance
guideline)
ISA3-F
Display value
0 to 60
Process data
0 to 3000
ISA3-G
Display value
0 to 300
Process data
0 to 3000
ISA3-H
Display value
0 to 500
Process data
0 to 2500
