No.JXC※-OMW1019-A
Contents
1. Safety Instructions 3
2. Product Outline 5
2.1 Product features 5
2.2 How to Order 6
2.3 Startup Procedures (changed) 7
3. Product Specifications 7
3.1 Outside dimension diagram 7
(1) Screw mount type (LECP6##-#-X120) 7
(2) DIN rail mount type (LECP6##D-#-XB120) 8
3.2 How to install 8
4. CN5: Parallel l/O Connector 9
4.1 Parallel I/O signals (changed) 9
(1) When the MODE input (Terminal No. A8) is OFF 9
(2) When the MODE input (Terminal No. A8) is ON 12
4.2 Parallel I/O Wiring Example 13
5. Setting Data Entry 15
6. Supplementary setting data input 15
7. Supplementary operation instruction mode 16
7.1 Operation when MODE is ON (Jog operation, teaching) 16
(1) Jog operation 16
(2) Teaching 17
8. Wiring of cables / Common precautions 18
9. Electric actuators / Common precautions 19
9.1 Design and selection 19
9.2 Mounting 20
9.3 Precautions for Use 20
9.4 Operating environment 21
9.5 Maintenance 22
9.6 Precautions for electric actuator with lock 23
10. Controller and its peripheral devices / Specific product precautions 23
10.1 Design and selection 23
10.2 Handling 24
10.3 Installation 25
10.4 Wiring 25
10.5 Power supply 25
10.6 Grounding 26
10.7 Maintenace 26
