SMC Networks LECP6 Series Supplementary Operation Manual

- 15 -
No.JXC※-OMW1019-A
5. Setting Data Entry
Step data changes
Step data is the actual data relating to the operation of the electric actuator.
There are 32 patterns of step data. Each of them has 1 item to be set.
Each step data will become effective as soon as it is written to the controller.
Example) Step data of the controller setting kit [Normal mode]
No.
Move
Speed
mm/s
Position
mm
Accel
mm/s
2
Decel
mm/s
2
PushingF
％
TriggerLV
％
PushingSp
mm/s
Moving F
％
Area1
mm
Area2
mm
In posn
mm
0
Absolute
100
20.00
1000
1000
0
0
0
100
18.00
22.50
0.5
1
Absolute
50
10.00
1000
1000
70
60
5
100
6.0
12.0
1.5
63
Absolute
20
5.00
500
500
0
0
0
100
3.0
8.0
1.2
6. Supplementary setting data input
Supplementary operation parameter details
Activation: “XX” = Become effective just after recorded into the controller
“X” = Become effective after restarting the controller
“－”= The parameter cannot be changed (fixed value)
Parameter name
Range
Description
Activa
tion
JOG speed
Basic parameter
The same range as “max.
speed”
Sets the speed during jog operation with JOG- /
JOG+ input terminal. (Unit mm/s)
XX
JOG acceleration
Basic parameter
The same range as “max.
Acceleration”
Sets the acceleration when the jog operation
starts with JOG- / JOG+ input terminal. (Unit
:
mm/s
2
)
XX
JOG deceleration
Basic parameter
The same range as “max.
Acceleration”
Sets the deceleration during jog operation stop
with JOG- / JOG+ input terminal. (Unit
:
mm/s
2
）
XX
JOG thrust
Step data
The same range as
“positioning force”
Sets the maximum torque during jog operation
with JOG- / JOG+ input terminal. (Unit %)
XX
Caution
Among the operation parameters, please do not change the parameters other than those described
in (1), motor parameter, basic value parameter and alarm parameter. Malfunction, damage or
burnout might occur.
