Made to Order
Symbol
Content
Page
X693
Special combination of piping directions
IN side: Straight
OUT side: Bottom entry
Page 73
X694
Special combination of piping directions
IN side: Bottom entry
OUT side: Straight
Page 73
X731
For Argon (Ar) and carbon dioxide (CO
2
) mixtures.
Mixture ratio (Ar : CO
2
) 92:8, 90:10, 80:20, 70:30, 60:40
Page 75
Accessories/Part number
If an accessory is required separately, order using the following part numbers.
Part number
Description
Remarks
ZS-33-D
Lead wire and connector
Length: 2 m
ZS-33-F
Connector cover (silicone rubber)
ZS-33-J
Panel mount adapter (without flow adjustment valve)
ZS-33-JS
Panel mount adapter (with flow adjustment valve)
ZS-33-M
Bracket (without flow adjustment valve)
Mounting screw 2 pcs.
ZS-33-MS
Bracket (with flow adjustment valve)
Mounting screw 3 pcs.
ZS-33-R
DIN rail mounting parts
