■Characteristics data
●Analogue output characteristics
: Analogue output at maximum rated flow rate when CO
2
is selected is 3 [V] for the voltage output type and 12 [mA] for the current
output type.
Model
Max. rated flow
[L/min]
PFM710--C/E
10 (5)
PFM725--C/E
25 (12.5)
PFM750--C/E
50 (25)
PFM711--C/E
100 (50)
: ( ): Fluid: CO
2
Model
Max. rated flow
[L/min]
PFM710--D/F
10 (5)
PFM725--D/F
25 (12.5)
PFM750--D/F
50 (25)
PFM711--D/F
100 (50)
: ( ): Fluid: CO
2
●Flow adjustment needle revolution - Flow characteristics
