Piping port specifications
Model
01
02
N01
N02
F01
F02
C4
C6
C8
N7
Thread type (Port size)
Rc
1/8
Rc
1/4
NPT
1/8
NPT
1/4
G
1/8
G
1/4
4
(5/32")
One-
touch
fitting
6
One-
touch
fitting
8
(5/16")
One-
touch
fitting
1/4
One-
touch
fitting
Weight
Straight
without flow
adjustment valve
95 g
125 g
55 g
Bottom entry
without flow
adjustment valve
105 g
135 g
65 g
Straight
with flow
adjustment valve
135 g
165 g
95 g
Bottom entry
with flow
adjustment valve
145 g
175 g
105 g
Material of parts in contact
with fluid
LCP, PBT, brass (electroless nickel plating), HNBR (+ fluoro coating),
FKM (+ fluoro coating), Si, Au, SUS304
Cable specifications
Conductor
Nominal cross section area
AWG26
Individual wire diameter
approx. 0.50 mm
Insulator
Outside diameter
approx 1.00 mm
Colours
Brown, White, Black, Blue
Sheath
Material
Lead free heat and oil resistance PVC
Outer diameter
approx. 3.5 mm
