-34-
No.PF※※-OMJ0006-G
The table below shows an example of the flow displayed when auto-shift zero is selected.
Here, a typical condition is used as an example
Operation example: Flow display before/after auto-shift zero at normal condition.
Flow display [L/min]
Before auto-shift
0
1.0
2.6
3.0
•••
8.0
9.0
10.0
Input auto-shift at 2.6







After auto-shift
.2.6

.1.6

0
0.4
•••
5.4
6.4
7.4
: When the flow value is negative, the left most decimal point indicates the presence of "-".
Set flow range when auto-shift or auto-shift zero is selected is as follows.
Set flow range when auto-shift or auto-shift zero is selected
Model
PFM710
PFM725
PFM750
PFM711
Set flow range
- 10.5 to 10.5 L/min
- 26.3 to 26.3 L/min
- 52.5 to 52.5 L/min
- 105 to 105 L/min
