Model Indication and How to Order
PSE3 T
PSE3
: A unit label is attached.
1: The new Measurement Law prohibits use in Japan of products with a unit selection function.
2: Fixed unit for compound, vacuum, low and differential pressure is: kPa
for positive pressure is: MPa (kPa for 500 kPa range model)
Options
Option products Model Note
Power and output cable ZS-28-A Length 2 m
Bracket ZS-28-B With set screws M3 x 5 L (2 pcs.)
Connector for sensor cable ZS-28-C 1 pc.
Panel mount adapter ZS-27-C With set screws M3 x 8 L (2 pcs.)
Panel mount adapter + Front protective cover ZS-27-D With set screws M3 x 8 L (2 pcs.)
Front protective cover ZS-27-01 1 pc.
DIN rail and terminal
base type
Option 1
Nil No option
L Power and output cable
Input/output specification
0 NPN open collector 2 outputs + 1 to 5 VDC Analogue output
1 NPN open collector 2 outputs + 4 to 20 mA Analogue output
2 NPN open collector 2 outputs + Auto-shift input
3 PNP open collector 2 outputs + 1 to 5 VDC Analogue output
4 PNP open collector 2 outputs + 4 to 20 mA Analogue output
5 PNP open collector 2 outputs + Auto-shift input
Unit specification
Nil Unit selection function provided
1
M SI units fixed
2
Option 2
Nil No option
A Bracket
B Panel mount adapter
D
Panel mount adapter
+ Front protective cover
Connector mounting
type
Option
Nil No option
E Front protective cover
Input specification
0 Voltage input
1 Current input
Option 3
Nil No option
C Connector for sensor cable
