SMC Networks ZK2-ZSV-A Series User Manual

-12-
NO.ZK2-OM00501-B
No.
Terms
Meaning
I
Indication accuracy
Shows the deviation between displayed pressure value and the true pressure.
Insulation resistance
Insulation resistance of the product.
The resistance between the electrical circuit and the case.
Indication resolution
How fine the rated pressure range can be segmented. (Example: If a product
for 0 to 1 MPa can indicate pressure by 0.001 MPa, the indication resolution is
1/1000.)
Indication LED
The LED that turns on when the switch output is ON.
Indication unit
The unit of pressure used in the display.
K
Key lock function
Function that prevents changes to the settings of the Pressure switch (disables
button operation).
M
Manual set up
Manual pressure setup without using auto preset.
This term is used to distinguish between manual and auto preset pressure
setup.
Max. applied voltage
The maximum value of applied voltage available to the output line of the NPN
output.
Max. (Min) load impedance
The maximum (minimum) load (resistance value and impedance) which can be
connected to the output (output line) of the analog current output.
Measurement mode
The condition in which the pressure is being detected and indicated and switch
operation is enabled.
Min. setting unit
Refer to "digit".
N
Normal output
One of the switch output types. In hysteresis mode the switch output is turned
ON when pressure equal to or greater than the switch output set value is
detected.
Refer to "List of output modes" on page 25)
NPN (open collector) (output)
The switch that uses the NPN transistor for output.
O
Output configuration
The operation principle of the switch output.
Refer to "List of output modes" on page 25 for the operation status.
Output mode
Either hysteresis mode can be selected.
A
