POSITIONING:
4 INSTRUCTIONS FOR TECHNICAL STAFF
4.1 Plumbinghookup
Watersupplyanddrainhookup
Thewaterpipelinesandelectricitysupplycableleadoutofthebottomright‐
handcorneroftheappliance.Connectthewaterintakehosetoaconnector
with ¾” gas threaded fitting, fitting the filter A provided (in models with
aquastop,thefilterandring‐nutformasingleunit).
Theconnectiontothewatermainsmustonlybemadewithnewhoses;the
useofoldorwornhosesisnotpermitted.
The dynamic water supply pressure must be between 1 and 6 bar; if it is higher, installation of a
pressurereducerisnecessary.
Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible
after installation of the appliance, so do
not install it behind the dishwasher. The stated cycle
duration applies to appliances supplied with hot water >50°C<60°C. If the dishwasher is supplied
withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.The
dishwasherisfittedwithadrainpumpandcanoperatewithdrainconnectionsonthefloororwall.
Refertotheconnectiondiagramforthemaximumpermittedheightofwalldrains–(seeTECHNICAL
DATA)
Caution:makesurethattheintakeanddrainhosesarenotbent,constrictedorcrushed
afterinstallation.
When installing the drain hose to a siphon with valve, the maximum height of the drain outlet is
reducedto600mm.
Caution:theindoorsystemandpremisesinwhichequipmentforinstitutionsisinstalled
mustcomplywiththerelevantregulations.
Themanufacturerdeclinesallliabilityfordirectorindirectinjuryordamagederivingfromfailure
tocomplywiththeseregulations.
Before installation, check that there are no objects or materials in the vicinity which may be
damagedbysteamorsplashesofwashingsolution,orthatanysuchitemsaresuitablyprotected.
Placethedishwasherinthechosenpointandremovetheprotectivefilm.
Levelthedishwasher(withtheaidofaspiritlevel)onitsadjustablefeettoensurethatitisstable;
allothermountingsolutionsmustbeapprovedbythemanufacturer.
