Smeg SW262 - Page 19

19
1) Extract the basket.
2) Open the retaining clip on both rails (see
white circle).
3) Extract it and put in position again by
inserting the upper wheels in the rail (see
white circle).
4) Close the retaining clip on both rails.
5) Loosen the ring nut of the water inlet funnel
by unscrewing it.
6) Lift the funnel until it is lined up with the
nozzle in the tank.
7) Once you get the right position, tighten it.
8) Check that the funnel and the tank’s nozzle
are coupled correctly.
