Smipack FP560 - Machine Components Description (FP560 A-FP870 A)

Chapter 2 - Machine installation
14
B) MODEL FP560A - FP870A
1
REEL HOLDER
8
OPERATOR PANEL
2
FILM PERFORATORS
9
CYCLE START MICROSWITCH
3
INFEED PRODUCT-HOLDING
PLATE
10
COOLING UNIT
4
SEALING FRAME
11
OUTFEED CONVEYOR BELT
5
SEALING BLADE
12
PACK DEVIATION DEVICE
6
ELECTRICAL PANEL
13
ROLLER UNIT
7
MASTER SWITCH
14
FILM SCRAP COLLECTION DEVICE
(optional)
Fig. 2.1.2
