Smipack FP560 - Packed Machine Dimensions and Weight; Machine Dimensions and Weight

Use and maintenance manual FP560 - FP560A - FP870A
15
2.2 WEIGHT AND DIMENSIONS OF PACKED MACHINE
2.3 MACHINE WEIGHT AND DIMENSIONS
X (mm) Y (mm) H (mm) WEIGHT (kg)
FP560
1400 880 1160 161
FP560A
1400 880 1160 177
FP870A
2125 1110 1293 320
Fig. 2.2.1
Fig. 2.3.1
X (mm) X1 (mm) Y (mm) H (mm) WEIGHT (kg)
FP560
1520 490 790 1050 129
FP560A
1520 490 790 1050 145
FP870A
2015 1035 1055 1125 267
