Smipack FP560 - Machine Access Areas for Inspections

Chapter 6 - Cleaning and maintenance
48
6.7 MACHINE ACCESS AREAS FOR INSPECTIONS
To facilitate the control operations in the main components of the machine have been prepared
special access areas that are described below.
A
Inspection of the keypad.
B
Inspection of the automated system for opening
and closing the sealing frame.
C
Inspection of the cooling system.
Fig. 6.7.1
Fig. 6.7.2
