Use and maintenance manual FP560 - FP560A - FP870A
13
2.1 DESCRIPTION OF THE MACHINE COMPONENTS
A) MODEL FP560
1
REEL HOLDER
9
ELECTROMAGNET
2
FILM PERFORATORS
10
CYCLE START MICROSWITCH
3
INFEED PRODUCT-HOLDING
PLATE
11
COOLING UNIT
4
SEALING FRAME
12
OUTFEED CONVEYOR BELT
5
SEALING BLADE
13
PACKAGE DEVIATION DEVICE
6
ELECTRICAL PANEL
14
ROLLER UNIT
7
MASTER SWITCH
15
FILM SCRAP COLLECTION DEVICE
(optional)
8
OPERATOR PANEL
CHAPTER 2 - MACHINE INSTALLATION
Fig. 2.1.1
