Smipack FP560 - Parameter Settings: Temperature & Ejection; Parameter Settings: Opening Delay & Auto Cycle

Chapter 5 - Operation and use
40
2 • Time for ejection of product from packaging area
This determines the time for ejection of the packed product from the packaging area.
Start-up of the conveyor belt is delayed only when this value is set at 10. This can be done
when the products to be packaged are particularly tall.
3 • Sealing frame opening delay
This delays opening of the sealing frame upon completion of the sealing phase.
4 • Automatic cycle of sealing process (only FP560A - FP870A)
By setting the parameter at ≠0, the machine carries out the sealing process automatically
without need for the operator to keep pressing the START button. Set the parameter at “0” to
disable it.
Fig. 5.6.1
(can be set from 1 to 10)
Fig. 5.6.2
(can be set from 0 to 10)
Fig. 5.6.3
(can be set from 0 to 1)
Fig. 5.6.4
(can be set from 0 to 1)
Sealing
Temperature 5,0
Output
Time 7,0
Opening
Delay 1,0
Automatic
Cycle 0,5
