55
Accessories
WIRING 2002 SYSTEM (RADION
®
8140)
REF# PART# DESCRIPTION QUANTITY
1* Antenna 1
2* 20-687-02 GPS Speed Sensor 1
3* 20-697-01 Radion 8140 Console 1
20-781 Radion Plastic Cover 1
4 20-734 Dashboard 1
5 20-540 Ram Mount 1
6* Wire Harness 1
7 15-743 Manifold Valve 1
8 18-007 Elbow 1
9 20-684 Flow Meter 1
10* 20-670-04 Pressure Sensor 1
11 20-685 Regulator Valve 1
12 33-509 Master Boom Control 1
13 33-216 Battery 1
* 20-697 TeeJet
®
Radion Kit (includes * items) 1
Use Dielectric Grease On All Electrical Connections
If using Simulated Speed with a Radion 8140, one needs to change back to Ground
Speed for proper rate control when spraying.
