Mx37y_Technical_Description_ENG_v2.00.doc
14
Mx37y
Single- and three-phase electronic meters with built-in DLC
modem, GSM/GPRS modem or RS485 comm. interface
3.4. Overall and fixing dimensions
(MT371)
Mounting and fixing meter dimensions comply with
the DIN 43857 standard.
Fig. 15a: Overall and fixing dimensions of an MT371
meter fitted with a long terminal cover
Fig. 15b: Overall and fixing dimensions of an MT371
meter fitted with a short terminal cover
Fig. 16: Overall and fixing dimensions of an MT371 meter
fitted with a switching device and a long terminal cover
