22
EEWB330B
8.0 USER FUNCTIONS
8.1 Data Recall
Use this function to
store or recall rim data (wheel
type,
diameter,
width,
Of
fset, ne mode, oz. mode and mm
mode) in or from the memory. 4 sets of wheel data (the
so-called user data) can be stored.
When it is turned ON the balancer sets the wheel data
regarding user A to the system default values and sets
the current user to user A.
To activate:
Press the “MODE” and the “Weight Placement”
keys simultaneously for 3 seconds. See Figure 31a.
The function starts with the SAVE option.
The data can be saved to the user displayed on
the right.
To clear the data (without saving):
Select Enter when user “- -” is displayed.
To save data:
Select + or – to scroll along User A, b, C or d.
Select Enter to save to the selected user.
The function proceeds with the RECALL option.
The data can be recalled from memory by selecting
the appropriate user. The selected user will be the new
current user, such as User b.
No recall required (no change in user required):
Select Enter when user “- -” is displayed.
To recall data:
Select + or – to scroll along User A, b, C or d.
Select Enter to recall the selected user.
The current available wheel data will be replaced
by the recalled data such as: “b”.
Figure 31a
+
