Snorkel TM12 Service Manual

Page 6-32
Illustrated Parts Breakdown - Label Kit, USA
Label Kit, USA
107012-011
Item Part Descrip on QTY.
1 0071927 DECAL,HYDRAULIC OIL 1
2 060197-001 DECAL,HYDROGEN GAS 1
3 514232-101 NAME PLATE 1
5 005221-000 DECAL, BATTERY FLUID 1
6 005223-005 DECAL, EMERGENCY DOWN 1
7 066554-000 DECAL, BEFORE OPERATING 1
8 510428-001 DECAL,UPPER CONTROLS 1
9 511093-000 DECAL “SNORKEL TM12” 2
10 101250-000 DECAL, MAX LOAD 500lbs 3
13 010076-001 DECAL, ATTENTION 1
18 061220-006 DECAL, ANSI 1
19 058534-000 DECAL, BATTERIES 1
20 066550-001 DECAL, DANGER 1
21 014222-003 DECAL, FORK LIFT 2
23 066555-000 DECAL, RELIEF VALVE 1
24 510429-002 DECAL, LOWER CONTROLS 1
25 066556-000 DECAL, COLLISION HAZARD 3
26 066522-000 D
ECAL, BATTERY CHARGER 1
27 101252-000 DECAL, MAX WHEEL LOAD (675lbs) 1
28 066556-001 DECAL, WARNING 2
29 107051-000 DECAL, BATTERY DISCONNECT 1
30 300699 DECAL, OPERATORS CHECKLIST 1
31 508771-000 DECAL, DO NOT REMOVE COMPONENTS 1
32 30
8772-000 DECAL, WARNING RESPONSIBILITIES 1
33 068635-001 DECAL, HARNESS HARD POINT 1
34 513859-100 DECAL ,EXT DECK SWL 1
35 514360-000 DECAL,PINCH POINT,FOR HANDRAILS 4
