Page 2 - TM12
OPERATION
Before operating the machine, ensure that the pre-operation safety inspection has been completed
and that any deciencies have been corrected. Never operate a damaged or malfunctioning ma-
chine. The operator must be thoroughly trained on this machine.
STEERING
NOTE: Steering is not automatically centred. Wheels must be returned to straight ahead position
by operating the steering switch.
1. Select DRIVE mode.
2.
While operating the interlock switch, push the steering switch to right or left to turn the
wheels in the desired direction.
Observe the tyres while manoeuvring the machine to ensure it moves in the correct
direction.
ELEVATING PLATFORM
NOTE: If the chasis inclination exceeds the specication maximum inclination value, the tilt alarm
will sound and the machine will not lift or drive. If the tilt alarm sounds, the platform must be low-
ered and the machine moved to a level location before attempting to re-elevate the platform.
1. Check clearances below and to the sides of the platform.
2. Select LIFT mode
3. While operating the joystick interlock switch, push joystick forward to the up position. The fur-
ther you push the joystick, the faster the platform will elevate.
LOWERING PLATFORM
1. Check clearances below and to the sides of the platform.
2. Select lift mode.
3. While operating the joystick interlock switch, pull back on the joystick.
TRAVEL WITH PLATFORM LOWERED
NOTE: The machine’s full travel speed range is enabled when the platform is in the lowered
(stowed) conguration.
1. Check that the route is level and capable of supporting the wheel load, clear of holes and
drop-offs, persons and obstructions.
2. Verify that the chassis key switch is turned to platform control and the chassis emergency stop
switch is on by twisting and pulling the button out.
3. After mounting the platform, ensure gates are close behind you.
4. Check clearances above, below and to the sides of the machine.
5. Be aware of the potential crushing hazards when holding handrails while the platform is mov-
ing in close proximity to other objects.
6. Twist and pull the platform controller emergency stops switch up to the on position.
7. Select drive mode.
8. While operating the joystick interlock switch, slowly push or pull the joystick forward or
reverse to travel in the desired direction.
The further you push or pull the joystick from the centre, the faster the machine will
travel.
11
