Page 4-7
Troubleshooting -7 - Hydraulic
4-7 H
YDRAULIC
Table 4-2: Hydraulic Troubleshooting Table
.\
Component
Function
Lift Platform
Lower Platform
Steer Right
Steer Left
Drive Forward
Drive Reverse
Creep
Depression Mechanism Extend
Depression Mechanism Retract
Brakes
Check Valve XX
Steering Cylinder X X
Lift Cylinder--CYL1 X
Depression Mechanism Cylinder XX
Brake Cylinder X
Suction Strainer XXXXXXXX
Return Filter XXXXXXXX
Drive Motors (2) XX
Pump XXXXXXXX
Main Relief Valve X XXXXXX
Steering Relief Valve X X
Lift Relief Valve X
Tank
Steering Right/Left Valve X X
Lift Valve X
Down/Emergency Lowering Valve X
Forward/Reverse Valve XX
Counterbalance Valve XXX X
To Next Page
