Snorkel TM12 Service Manual

Controls Section 3 - Service & Repair
Page 3-26
C HASSIS C ONTROLS
Figure 3-20: Chassis Controls
The chassis control assembly is mounted on
the inside of the chassis door, to the left of the
Hydraulic tank.
Right Side Door
1
2
3
6
7
5
1. Emergency Stop
2. Contact Block (Emergency
Stop)
3. Enable Button / Contact Block
4. Overlay
5. Toggle Switch (Up / Down)
6. Cable Gland
7. Control Box
510429-001
3
1
4
5
4
0
8
8. Key Switch
8
