Snorkel TM12 Service Manual

Page 6-15
Illustrated Parts Breakdown - Hydraulic Tank Assembly
505115-003
Hydraulic Tank Assembly
Item Part Description QTY.
1
1
1
1
1
512545-000 TANK (PLASTIC)
2 512566-000 RETURN FILTER (ELEMENT 510696-001)
3 512565-000 BREATHER CAP
4 512575-000 SUCTION STRAINER
5 011937-001 ADAPTOR 90°
6 514362-000 STRAIGHT ADAPTOR
1
17 512951-000
18 512577-000
1
STRAIGHT ADAPTOR
STRAIGHT ADAPTOR
1
8
2
5
6
7
3
Tank Assembly
4
