Snorkel TM12 Service Manual

Page 2 - TM12
MAINTENANCE CHECKLIST
DAILY PREVENTATIVE MAINTENANCE SCHEDULE
MAINTENANCE TABLE KEY PREVENTATIVE MAINTENANCE REPORT
Y = Yes/Acceptable Date: ______________________________
N = No/Not Acceptable Owner: _____________________________
R = Repaired/Acceptable Model #: ____________________________
Serial #: ____________________________
Serviced by: _________________________
Table 2-2: Daily preventative maintenance
checklist
* NOTE: Use ISO #46 during summer
and ISO #32 during winter
21
Operator’s
Manual
Check that the operators manual is in
the manual holder and all pages are
intact and readable
Labels &
Decals
Check that labels and decals are in
place, intact and readable
Entire Unit Perform pre-operation inspection
Check for and repair any damage
Electrical
system
Check cables and wiring harness condi-
tion (No wear or physical damage)
Battery
System
Check electrolyte level, (if applicable).
Check battery cable condition
Check terminals are clean and connec-
tors are tight
Check charger condition and operation
Charge batteries
Hydraulic
Check oil level
Hydraulic
system
no leaks
Drive motors Check for operation and leaks
Hydraulic
pump
no leaks
Emergency
lowering
Check emergency lowering correctly
(See emergency lowering procedure)
Controller Check condition and operation
Platform
deck and
rails
Check fasteners are in place, correctly
tightened and not damaged
Check the structure and welds for dam-
age, deformation, corrosion and cracks
Check condition of deck (no damage,
deformation, corrosion or cracks
Check entry gate closure functions
correcly
Elevating
assembly
Inspect for external damage, dents, loose
rivets or cracks, loose chain tensioner
locknuts
Check the structure and welds for dam-
age, deformation, corrosion and cracks
Chassis Check cables for pinch or rubbing points
Check the structure and welds for dam-
age, deformation, corrosion and cracks
Lift Cylinder Check for leaks
Wheels Check for loose components
Check for damage to tyres
Harness
anchor point
Check fasteners are secure
Check for damage, deformation, corrosion
and cracks
System func-
tion inspec-
tion
Conduct system function inspection (see
system function inspection pocedure)
Emergency
stops
Check that the emergency stop button on
the basket panels opertates correctly
Check that the emergency stop button
on the ground control panel operates
correctly
Brakes Check that the brakes operate correctly
Horn Check that the horn sounds when acti-
vated
Proximity
switch and
controller
Check armguard lowering functions cor-
rectly when the platform is being lowered.
Check full drive speed range is enabled
when the platform is stowed.
Check that only reduced drive speed
range is enabled when the platform is
elevated.
COMPONENT
INSPECTION OR SERVICES
Y N
R
COMPONENT
INSPECTION OR SERVICES
Y
N
R
