Page 2 - TM12
SPECIFICATIONS
ITEM TM12
Platform size 740 mm X 960 mm (29” X 38”)
Maximum platform capacity 227 kg (500 lbs)
Maximum number of occupants 2 people indoors/1 person outdoors
Maximum manual force A) per occupants: 200N (45 lbs) maximum
B) two occupants: 400N (90 lbs) maximum
Maximum wind speed 12.5 m/s (28 mph) [Beaufort scale 6]
HEIGHT
Working height
Maximum platform height
Minimum platform height
5600 mm (18ft)
3630 mm (11 ft 11”)
4830 mm (19”)
DIMENSIONS
Weight
Overall width
Overall height
Overall length
912 kg (2010 lbs)
760 mm (30”)
1650 mm (65”)
1360 mm (53.5”)
DRIVE SPEED
Platform lowered
Platform raised
3.2 km/h (1.99 mph)
0.43 km/h (0.27 mph)
PLATFORM OPERATION SPEED
Platform lowering
Platform raise
19 seconds
16 seconds
Energy source 24V battery pack
Four 220 ampere hour, 6 volt batteries, min. wt. 26.3 kg (58 lbs) each
4HP DC electric motor
System voltage 24 VDC
Battery charger 25 AMP, 220 V AC 50 Hz
Battery duty cycle 25% for 8 hours
Hydraulic reservoir capacity 7.2 L (1.9 gal)
Maximum hydraulic system pressure 165 bar (2400 psi)
HYDRAULIC FLUID
Normal above 32
o
F [0
o
C]
Low temperature below 32
o
F [0
o
C]
Below 0
o
F [-17
o
C]
ISO #46
ISO #32
ISO #15
Lift system One single stage lift cylinder
Drive control Proportional
Control system Proprotional control handle with interlock, selector switch, red mush-
room emergency stop switches
Horizontal drive Dual front wheel
Tyres 305 mm (12”) diameter solid rubber, Non - marking
Parking brakes Dual, spring applied, hydraulic release
Turning radius 370 mm (14.5”) inside
Maximum gradeability 14
o
(25%)
Wheel base 978 mm (38.5”)
Guardrails 1100 mm (43”)
Toeboard 152 mm (6”)
Maximum chassis inclination (see page 19 for 2 degree side to side
option)
2.0
o
side to side
2.0
o
front to back
Wheel loading no extension deck 325 kg per wheel / 716 lbs per wheel
Wheel loading with Extension deck 370 kg per wheel / 815 lbs per wheel
