Page 6-19
Illustrated Parts Breakdown - Hydraulic Assembly
LIFT CYLINDER
DRIVE MOTOR 1
DRIVE MOTOR 2
STEERING CYLINDER
PUMP MOTOR
HYDRAULIC OIL
TANK
HYDRAULIC
MANIFOLD
BRAKE CYLINDER
POTHOLE CYLINDERS
