Page 6-24

Illustrated Parts Breakdown - 32

Electric Kit

510520-000

Harness Kit

510950-000

pircseD.oN traPmetI

on Qty per

512950-001

512950-002

Ground Control Loom 1

512950-003

1selbaC evlaV

Kit Qty Part Number Description

1 510522-000 Toggle Switch SPDT (on)-off-(on)

1 510521-000 Toggle Switch, on-(on)

1 510524-000 Twist to Release Emergency Stop

1 510525-000 Normally Closed Contact Block

2 510527-000 Normally Open Contact Block

1 510541-000 Toggle Switch SPDT on-on

1 510542-000 Black Flush Pushbutton (Horn Pushbutton)

1 510524-000 Twist to Release Emergency Stop

1 510525-000 Normally Closed Contact Block

1 510527

-000 Normally Open Contact Block

1 510528-000 R

ed LED, Prominent 24VDC

1 501868-000 Disk Type Horn, High Note Continuous, 24V

1 502494-000 Fork Lift Truck Fuses, 175A

1 446086 Fuseholder

1 502588-000 Continuous Audible Alarm, 80-95dB, 4-28VDC

1 512684-000 Right Angled Bracket, for Mounting Buzzer

1 502489-000 WR DC SolenoidContactor

3 514182-000 Toggle switch rubber boot

Ground Control Box

Platform Control Box

External Components
