11. CHARACTERISTICS
Electrical characteristics
AC operating limits 184 - 300 VAC
(2)
Optional DC supply 24 VDC
Frequency limits 45 - 65 Hz
Power consumption < 10 W
Inputs
5 - fixed (auto inhibit & 24 VDC fire input,
position indication I-0-II)
Outputs 4 - fixed (position control I-0-II & genset start)
Impulse withstand 6/4 kV
(1)
Overvoltage category CAT 3
Mechanical characteristics
Weight 845 gr
Door cutout 138 x 92 mm
Operating temperature -25 … +60°C
Communications
Interface type RS485. 2 to 3 half duplex wires
Protocol MODBUS RTU
Baudrate 38400
(1) 6 kV tested between phases of a different source and 4 kV tested between phases of a the
same source.
(2) 190 - 300 VAC in contactor mode.
12. PREVENTIVE MAINTENANCE
WARNING
Maintenance operation should be done by trained and qualied personnel using
the appropriate protection equipment.
It is recommended to verify at least once a year the tightening torque of all connections and to operate the product in a full
operating cycle (I – 0 – II – 0 – I: Auto and Manual) as well as tightening the door mounting clips and testing the LED’s with the
lamp test button when applicable.
In case of upstream protection tripping (fuse protection / Circuit breakers) make sure that the ATS remains functional by doing a
functional test with the RTSE connected to the controller.
To clean the front face of the equipment, use a soft cloth with water and non-abrasive liquids.
Note: Maintenance should be planned carefully and carried out by qualied and authorized personnel. Consideration of the critical
level and application where the product is installed should form an essential and integral part of the maintenance plan. Good
engineering practice is imperative whilst all necessary precautions must be taken to ensure that the intervention (whether directly
or indirectly) remains safe in all aspects.
