socomec Masterys Green Power - Unpacking Procedure

ENGLISH
IOMMASGPXX01-GB_01 9
10-40 kVA
3
UNPACKING AND INSTALLATION
OF THE UNIT
3.2 UNPACKING PROCEDURE.
3.2.1 Models “S” (h 800 mm) and models “M” (h 1.000 mm).
3.2.1-3
Remove screws A and screws B.
A
B
3.2.1-5
Secure the UPS with feet C.
C
C
3.2.1-23.2.1-1
3.2.1-4
1
3
2
The UPS can be moved.
Place the UPS in the installation
area.
Secure the UPS with feet D only when it is in position with cables
connected.
