socomec NETYS RT 5000 User Manual

NETYS RT 5 - 7 - 9 - 11 kVA - 551570A - SOCOMEC
33
EN
5.10.2. Standard conguration
SW1 SW2 Relay
contact
OFF OFF NO
ON OFF NC
GND-R: Relay ground contact
Common: 12~24 V DC
R1 General alarm
R2 No mains
R3 Battery low
R4 On by-pass
R5 Overload
R6 Overtemperature
Input: Remote shutdown or battery test
5.10.3. Customized conguration for relay and/or input contacts
Connect Tx to pin 2, Rx to pin 3 and GND-C to pin 5 of the computer’s RS232 port.
In Windows, start the Hyper-Terminal application and proceed to open the specied COM port.
Set the following properties: Baud rate: 2400, Data Bits: 8, Parity: None, Stop Bit:
1, Flow Control: None.
Conguration
Press <Enter> to display the main menu of the relay card.
UPS Relay Card
Firmware Version: Relay Card V1.4
[1] . Customize Output Relay
[2] . Congure Input Signal
[3] . Customize Normal Open or Normal Close
[0] . Quit
Please Enter Your Choice >
