- 21 -
SR4 MANUAL
DRY
WET
STUB AXLE HEIGHT
FRONT TRACKING WIDTH
REAR TRACKING WIDTH
REAR AXLE POSITION
POSITION OF MASSES
POSITION OF EXCENTRICS
1°
POSITION OF STEERING TIE
RODS ENDS
10-STANDARD ADJUSTMENTS OF THE SR4
4mm
4mm +2mm
HIGH
1
2
1400
1354
4mm+4mm
2mm
HIGH
FOR TYRE PRESSURES , REFER TO TABLE PAGE 33
TOP
BOTTOM
FW
D
TOPT
BOTTOM
FW
D
B-2
B-2
3
3
21
23
Table of Contents
Default Chapter
2
Table of Contents
2
Safety Instructions
4
Preparing the Assembly
5
1- Getting Sr4 out of the Packing
5
2- Tools for Assembly
6
3- Maintenance Products
6
Sequence of Assembly
7
4- Assembly of the Steering Column and of the Steering Wheel
8
5- Assembly of the Fuel Tank and of the Overflow Bottle
10
6- Assembly of the Seat and of the Seat Stiffeners
11
7-Assembly of the Kg Unico Body Work
14
8- Assembly of the Sodi Body Work
17
9- Starting Your Sr4
21
10- Table of the Standard Adjustments
22
11- Adjustment of the Front End
23
Standard Adjustments
26
12- Adjustment of the Rear End
29
13- Adjustment of the Seat
32
Maintenance
33
14- Tyres
33
15- Brake Pads Replacement
35
16- Bleeding of the Brake System
36
17- Cleaning the Chassis
37
18- Maintenance Plan
38
19- Trouble Shooting
39
