Sodi SR4 User Manual

- 22 -
SR4 MANUAL
11- ADJUSTMENT OF FRONT WHEELS
11.1 ADJUSTMENT OF FRONT TRACKING WIDTH
DRY TRACK
 Place the rings on the slotted round nut side (1).
WET TRACK
 PLACE THE RINGS ON THE STUB AXLE FORK SIDE (2).
(1) DRY TRACK
1X15 mm
3x5mm
(2) WET TRACK
1X15 mm
3x5mm
 For more grip forward , place one
or two 5 mm rings on the chassis
side.
Steering becomes harder.
HUB
HUB
 For less grip forward , place one
or two 5 mm rings outside.
Steering becomes lighter.
