- 23 -
SR4 MANUAL
11.2 ADJUSTMENT OF FRONT WHEEL HEIGHT
DRY TRACK
Place one 4mm spacer on top and one 4 mm + one 2 mm spacer at the bottom (1).
WET TRACK
Place one 4 mm + one 4 mm spacers on top , and one 2 mm spacer at the bottom (2).
(1) DRY TRACK
4+2mm
4mm
(2) WET TRACK
4+4mm
2mm
