SR4 MANUAL
15- CHANGING BRAKE PADS.
 Unscrew the piston adjustment screw
to its back stop (1).
 Remove the 4 screws with springs (2).
 Remove the safety pin (3).
 Remove the pads!; insert the new
ones(4) .
 Insert the safety pin (3).
 Place the 4 screws with springs with
drop of glue.
 Tighten the screw (1) until the pads
touch the disk!; unscrew (1) by one
and one quarter of a turn to get the
gap between the pads and the disk.
ADJUSMENTS!: the adjustment of the gap between the disk and the pads is done
with the screw (1).The standard gap is 1 mm.
ATTENTION
2
1
3
 The brake system is a key safety item of the kart. Regularly check all its components . In
case of doubt, do not drive before fixing the problem .
 Bad maintenance of the brakes can lead to severe, even fatal injuries.
 Never repair a break system on your own; return it to SODIKART through your local
dealer.
