16- BLEEDING THE BRAKE SYSTEM
1- Take a petrol hose and put it on the bleed screw (3) .
2- Press the brake pedal (1 ) and maintain the pressure.
3- Open the bleed screw (3); liquid and air bubbles come out.
4- Close the bleed screw (3).
5- Release the brake pedal.
6- Fill the brake liquid tank with LU842.013.
7- Make sure the maximum level is (2 ).
Repeat operations 3 to 8, until the brake pedal becomes hard.
NOTE!:
The brake system must be regularly checked!: level of brake fluid, cover of the fluid
reservoir, state of screws and bolts …!;.
If the brake fluid becomes black, bleed and change it.
Bleed and change the brake fluid after each brake pads replacement .
The gap between the brake disk and the brake pads is 1 mm .
