Sodi SR4 - Assembly of the KG Unico Body Work

- 13 -
SR4 MANUAL
7-ASSEMBLY OF THE KG UNICO BODY WORK.
7-1 PREPARING THE KG UNICO SUPPORTS.
In order to comply with the CIK/FIA rules , carefully prepare the supports as indicated below.
( Measurements in mm )
SPOILER LOWER SUPPORT
SPOILER UPPER SUPPORT
End to cut
End to cut
NOT COMPLYING WITH THE CIK/FIA RULES MAY LEAD TO DISQUALIFICATION DURING
A COMPETITION .
NOTE!:
DRILL 6.5 MM DIAM HOLE,
HORIZONTAL
DRILL 6.5MM DIAM HOLE,
VERTICAL
