Connection of PC and device
A connection between PC and device is required for:
• Online configuration
• Transfer of a parameter file from PC to device and vice versa
• Diagnostic and test functions
• Programming of the S5 / S7 via network
The connection between PC and device can be established indirectly via bus.
Basic configuration
The echo device is configured with the NetCon software.
Resetting the device to default settings
Start the configuration software.
Select “Offline”.
Enter the file name “netfile.net”. This file must be located in the main directory of the SD card.
Set the Station Parameters to the desired values. For the MAC address, you can either leave 00
00 00 00 00 00 – in this case, the hardware address of the device will be used – or you can enter
the desired MAC address.
Exit the configuration software.
Insert the card in the device.
Restart the device.
The device has the specified parameters; all the connections have been removed. You can use any
configuration file you have created.
Remove the card from the device. If you leave it inserted, all the parameter settings will
be reset every time you switch on the device.
