Power
12
NOTES
The Tamper, Low Battery, and AC power fail inputs must be enabled and
connected to the iSTAR Ultra to report for compliance with UL requirements.
For UL listed products, burglar alarm inputs must be supervised.
UL Listed panic hardware shall be used to allow emergency exit from a
protected area.
All inputs and outputs, except FAI and Ethernet must be shielded.
The USTAR-GCM AC Fail/Lo Batt and COMM, USTAR-GCM and USTAR-ACM
Tamper, USTAR-GCM power, USTAR-ACM power (Reader), USTAR-ACM lock
1 and lock 2 connections are not to leave the room of installation or 25’ beyond
control unit. Therefore, these connections were not tested for output transients.
To Next Page
